ASME SA387, ASTM A387 Chrome Moly Alloy Steel Plates

/, Steel Plates, Steel Sheets/ASME SA387, ASTM A387 Chrome Moly Alloy Steel Plates

ASME SA387, ASTM A387 Chrome Moly Alloy Steel Plates

130.00 120.00

SA387/A387 Chrome Moly Alloy Steel Plates Suppliers – Call Us Now!

“Yes, It’s in Stock and Ready to Deliver”

High Quality, Lower Cost But The Best Service in Chrome Moly, A387 Steel Plates

Metline Industries is a leading stockholder and supplier of ASME SA 387/ASTM A387 grade steel plates, also commonly known as chrome moly steel plates. We can supply cut to size chrome moly steel plates, with both narrow and wide widths. Our stock of A387 steel plates includes thickness of 6mm up to 200mm with width of 1500mm, 2000mm, and 2500mm. All plates supplied by Metline Industries, are accompanied with relevant Mill Test Certificates and complete traceability. Most commonly used A387, Chrome moly grades include:

  • ASTM/ASME A387 Grade 5 Class 2
  • ASTM/ASME A387 Grade 11 Class 1, Class 2
  • ASTM/ASME A387 Grade 12 Class 2
  • ASTM/ASME A387 Grade 22 Class 2
  • Order Large or Small Quantity of A387 Grade Steel Plates, Chrome Moly Plates
  • Cut to Size A387 Grade Steel Plates, Chrome Moly Plates Available
  • No Minimum Order Quantity for A387 Grade Steel Plates, Chrome Moly Plates

Description

A/SA-387 Steel Plate Suppliers, Grades 5, 9, 11, 12, 22 and 91 Class 1 and 2 – Chromium Molybdenum Alloy Steel Plates

The ASTM specification A387 covers chromium- molybdenum (Cr-Mo) alloy plate steels intended for elevated temperatures, greater corrosion resistance and hydrogen service pressure- widely used in boilers and pressure vessel manufacturing.

Widely known for manufacturing pressure vessels, A387 Chrome Moly plates are available in various grades including Grade 5, Grade 9, Grade 11, Grade 12, Grade 22 and and Grade 91. These grades can be further classified in either class 1 or 2. Metline Industries is a leading supplier of A387 grade plates in various widths and lengths. We can also supply A387 chrome moly plates in cut to size forms, as per customer requirements.

Are You Looking to Buy A387/SA387 Alloy Steel Plates  – Call Us Now – We can Offer Ex-stock Deliveries

Call Us for Best Discounted Prices for A387/SA387 Alloy Steel Plates ! Low Prices, Best Quality

What is the Chemical Composition of A387/SA387 Alloy Steel Plates or Chrome Moly Steel Plates?

A387/SA387 Alloy Steel Plate Chemical Properties:
A387/SA387 Grade 5 Grade 9 Grade 11 Grade 12 Grade 22
Carbon 0.15 max 0.15 max 0.04-0.17 0.04-0.17 0.04-0.15
Manganese 0.25-0.66 0.25-0.66 0.35-0.73 0.35-0.73 0.25-0.66
Phosphorous 0.035 0.03 0.035 0.035 0.035
Sulfur 0.03 0.03 0.035 0.035 0.035
Silicon 0.55 max 1.05 max 0.44-0.86 0.13-0.45 0.5 max
Chromium 3.9-6.1 7.9-10.1 0.94-1.56 0.74-1.21 1.88-2.62
Molybdenum 0.40-0.7 0.85-1.15 0.40-0.7 0.4-0.65 0.85-1.15



What are the Mechanical Properties of A387/SA387 Alloy Steel Plates or Chrome Moly Steel Plates?

A387/SA387 Alloy Steel Plate Mechanical Properties:
Grade A 387 Grade 5 A 387 Grade 9 A 387 Grade 11 A 387 Grade 12 A 387 Grade 22
Class 1 Class 2 Class 1 Class 2 Class 1 Class 2 Class 1 Class 2 Class 1 Class 2
Tensile Strength (ksi) 60-85 75-100 60-85 75-100 60-85 70-90 50-80 60-85 60-85 75-100
Tensile Strength (MPa) 415-585 515-690 415-585 515-690 415-585 485-620 380-550 415-585 415-585 515-690
Yield Strength (ksi) 30 45 30 45 35 45 33 40 30 45
Yield Strength (MPa) 205 310 205 310 240 310 230 275 205 310
Elongation in 200mm (%) 19 18 18 19
Elongation in 50mm (%) 18 18 18 18 22 22 22 22 18 18
Reduction of area in % 45 45 45 45 45 45

Additional information

Main Alloy Steel Grades

ASTM A387 GRade 22 Class 2, ASTM A387 Grade 11 Class 2

MOQ

50 kg's to Production Qty's

Delivery time

Promptly (Stock) or 10-40 days (Production)

Stock

Available

MTC

Mill TC EN 10204 3.1, Third Party Inspection, NDT/DT Test Reports
